SEM with intuitive operation, high-resolution imaging, and elemental microanalysis.
Keyence VHX-6000- 0.5x – 5000x
- One-press auto-focus
- Image stitching
- Generate 3D image
Portable Mahr Marsurf PS10 roughness meter with internal roughness meter calibration gauge
Machine for plasma electrolytic polishing PePeptopus 80
MAKINO EDAF2 is an EDM sinking machine with tank size 700 x 500 x 300 mm and max electrode weight 75 kg.
- BMF micro Arch 240
- Print vol. (x-y-z): 100x100x75 mm
- Print acc: 0.0005/0.002 mm(top/side)
- Layer (max/min): 0.01/0.04 mm
- Working table (x-y): 100×100 mm
- Min. structure dimensions: 1 μm
- Typical structure height: 1 – 200 μm
Spin coater Laurell WS-650MZ-8NPP
- Max. substrate dim.: 100×100 mm
- Min. layer thickness: 0.5 μm
- Max. layer thickness: 100 μm
Babyplast 6/10P machine for microinjection of thermoplastic materials. Max. injection volume: 4 cm3.
- Model: Omax 2652A
- HP water pump: Bohler Ecotron 403
- Max cutting size: 1500×600 mm
- Cut accuracy: ±0,1 mm
Universal milling / drilling machine
- Print vol. (x-y-z): 215x215x200 mm
- Printing accuracy: ±0,3 mm
- Layer height (max/min): 0,2/0,06 mm
- Printing vol. (x-y-z): 223x223x205 mm
- Printing accuracy: ±0,3 mm
- Layer height (max/min): 0,2/0,1 mm
- Print vol. (x-y-z): 220x220x250 mm
- Printing accuracy: ±0.1 mm
- Layer height (max/min): 0,1/0,4 mm
- Print vol. (x-y-z): 120x68x200 mm
- Printing accuracy: ±0.053 mm
- Layer (max/min): 0.1/0.035 mm
- Print vol. (x-y-z): 143 x 90 x 165 mm
- Printing accuracy: 35 microns
- Layer height (max/min): 10 microns
Link to the complete equipment list.
